| 規格 | |||||
| 型號 | XFC-301 | XFC-300 | XFC-210 | XFC-110 | XFC-100 |
| 額定電壓 | 220–240V AC 50/60Hz | 220V, 230V, 240V AC 50/60Hz | 110–130V, 220–240V AC 50/60Hz | ||
| 耗電量 | 400–460W | 470W | 420–470W, 380–420W | ||
| 電源線長 | 1.5m Inlet type | 1.1m (3 core cord) ground plug | |||
| 溫度設定范圍 | 50–550°C | 150–550°C | 150–450°C | ||
| 絕緣電阻 | Over 10MΩ (500V DC) | ||||
| 本體 | |||||
| 型號 | XFC-301 | XFC-300 | XFC-210 | XFC-110 | XFC-100 |
| 電壓 | 220–240V AC | 220V, 230V, 240V AC | 110–130V, 220–240V AC | ||
| 風量計 | 帶風量儀表 | − | |||
| 風量范圍 | 5–25L /min | 5–23L /min | 5–25L /min | 5–20L /min | |
| 自動升降功能 | 有 | - | |||
| 模式種類 | 3 (Profile-Normal, Profile-Auto, Hand) | 3 (Profile-Flat, Profile-Slope, Hand) | 1 (Hand) | ||
| 溫度記錄 | 五個區域(溫度和時間) | − | |||
| 過程記錄 | ( Auto, Normal )×19, HAND×1 | ( Flat,Slope)×19, HAND×1 | − | ||
| 尺寸 | 200(W) ×230(H) ×265(D)mm | 182(W) ×179(H)× 263(D)mm | 107(W) ×177(H)×227(D)mm | ||
| 重量 | 7.6kg ( w/o cord ) | 8.4kg ( w/o cord ) | 7.8kg ( w/o cord ) | 4.6kg ( w/o cord ) | |
| 配件 | 預熱臺連接線、手柄支架、真空吸盤一套、XVCW-SET | 手柄支架、真空吸盤一套、XVCW-SET |
手柄支架 |
||
| 手柄部 | ||||||
| 型號 | XFC-301 | XFC-300 | XFC-210 | XFC-110 | XFC-100 | |
| 電烙鐵部電壓 | 220-240V AC | 220V, 230V, 240V AC | 110-130V AC | 220-240V AC | ||
| 耗電量 | 370-430W | 400W | 400-450W | 300-400W | ||
| 發熱芯 | Nichrome Heater | |||||
| 電烙鐵部軟管長 | 1m | |||||
| 真空吸頭 | Integrated into Handpiece | − | ||||
| 尺寸 | 220mm (w/o cord) | |||||
| 重量 |
180g (w/o nozzle, cord) |
|||||
